Housing Master Plans

A regional partnership for achievable housing bannerDescription

The Housing Master Plans is a regional partnership with Nevada County, Sierra County, Placer County, Town of Truckee, City of Grass Valley, and City of Nevada City along with design partners Russell Davidson Architect and Jackson & Sands Engineering, Inc. to provide flexible housing options to the public. This program aims to reduce design cost and plan review for single family or accessory dwelling units.

Options and Site Information Form

The options and site information form must be completed and submitted when applying for a building permit using the plans below. Use the form to select your custom options, such as plan type, roofing material, garage/no garage, heating source, etc.

Download the project Options and Site Information Form.

Before you apply for a permit, there are a few things to consider:

  • Verify that your septic system and well can accommodate the additional dwelling unit. Please contact Environmental Health with any septic/well questions.
  • Prepare your site plan. The site plan should show all development on the parcel, including the proposed location of the new structure and any supporting utility. Please refer to the plan submittal checklist for more details.
  • Verify your property setbacks or restrictions are in compliance. Please contact the Planning Department to discuss your proposed building site and to obtain your property setbacks.
  • Consider if you need to grade your parcel for the addition of the new structure. If so, you will need to submit grading plans as part of your plan submittal.
  • Look into development standards for accessory or second dwelling units. They can be found on the ADU FAQ handout.

For a complete plan submittal, please ensure you include the following:

  • Site plan
  • Receipt from Jackson & Sands Engineering, Inc.

For more information regarding the permit process, please contact the Building Department or check out the Permit Process Overview page. See the Housing Master Plan Handout for a printable quick reference guide.

How to Apply

The plans cost $1200 per use, and payment must be made to the design consultant prior to applying for a permit.  For information about purchasing the right to use the plans, contact Jackson and Sands Engineering, Inc. at adu@jacksonandsandsengineering.com.

To apply for a building permit, use the Nevada County Citizen Access Portal. When prompted to upload plans, use the floor plan and elevations file available to download below and your receipt.

If you have other questions, contact the Building Department at 530-265-1222 or via email at BuildingDept@nevadacountyca.gov.

Design Philosophy

Each ADU has been designed to be adaptable to various locations, styles, and budgets, providing homeowners with a customizable living space that suits their unique needs and preferences. All plans can be utilized as either a slab or raised floor, providing versatility to accommodate different foundation options. The designs were created to enable owners to modify the facade and elements, so they can reflect the surrounding environment, aesthetic preferences, and existing structures.

Additionally, the designs are created to be as cost-effective as possible, utilizing space efficiently without sacrificing comfort and functionality. The open-concept living areas provide a welcoming atmosphere, while the separate bedroom zones offer privacy. The inclusion of features such as covered outdoor spaces and optional garages further enhance the flexibility of the designs.

2 story ADU with 1-bedroom, 1-bathroom over 2-car garage with exterior access to dwelling

661sf conditioned
661sf garage

This 661 sf house with 1 bedroom, and 1 bathroom situated above a garage and storage space is an excellent choice for those seeking an efficient and compact living space. Its open plan design combines the living, dining, and kitchen areas, providing a flexible and functional space. The bedroom entrance is located away from the living space, making it ideal for those who want both efficiency and privacy.

Downloads: Floor Plan and Elevation | Bid Set (Full set of plans for estimates)

1 Bedroom Front View

Single-story 2-bedroom, 1-bathroom single-family dwelling/ADU with or without 1- car garage

747sf conditioned
315sf optional garage

This 747 sf 2 bedroom, 1 bath house features open living space and a separate bedroom wing all covered by a simple gable roof. The rear patio and covered entry offer outdoor living space while still providing shelter from the elements. By incorporating a simple roof and separate living and bedroom volumes, this design allows for a wide range of customizable aesthetics and design options. With this design, owners have the freedom to create a space that reflects their unique style and preferences.

Downloads: Floor Plan and Elevations | Bid Set (Full set of plans for estimates)

2 Bedroom Front View

Single story 3-bedroom, 2-bathroom single-family dwelling/ADU with or without 2-car garage

1,194sf conditioned
480sf optional garage

This 1,194 sf, 3 bedroom, 2 bath house features open living space with access to a covered patio or an optional garage. The primary bedroom has an en suite bathroom for additional privacy. The second bathroom is conveniently located for guests while still maintaining privacy for the bedrooms. The open living space provides ample living space, practicality, and versatility, making it an excellent choice for anyone seeking a comfortable and functional ADU.

Downloads: Floor Plan and Elevations | Bid Set (Full set of plans for estimates)

3 Bedroom Front View
